COMPARELAUNCH EV Oscilloscope & Multimeter EM101N
The LAUNCH EM101N is a 2-in-1 EV oscilloscope and multimeter—combining a dual-channel
oscilloscope with a full multimeter tailored for high-voltage vehicle diagnostics.
Its waveform viewing enhances maintenance accuracy,
and the user-friendly diagnostic app supports local waveform storage.
Country of Origin: China
- Combined with the characteristics of dual-channel oscilloscope and multimeter.
- The anti-fall rubber sleeve increases the protection of the product, and the unique fuse plug-in design is convenient for replacement.
- With X-431 diagnostic tool, it can be connected wirelessly or in wired mode, which can be freely selected.
- With X-431 diagnostic tool, the new UI design supports three display modes, which can be freely switched.
- Needle sets, multimeter pens, alligator clips, oscilloscope channel test leads, etc. are all available.
| Name | - |
|---|---|
| Channels | Two analog channels |
| DC Voltage | Automatic range, test range: ±600V |
| AC Voltage | Automatic range, test range: ±600V |
| DC Current | Automatic range, test range: ±10A (It is necessary to connect an external sensor for large range current.) |
| AC Current | Automatic range, test range: ±10A. Average value measurement (It is necessary to connect an external sensor for large range current.) |
| Resistance | Automatic range, test range: 0~6MΩ |
| On and off | Tweet when less than 30Ω |
| Diode | 0.5V—2.0V |
| Battery Capacity | 3100mAh |
| Bandwidth | 10MHz |
| Real-time Sampling Rate (Max) | 50MHz/s |
| Time Base Range | 1us/div～10s/div, step by 1～2～5 times |
| Sampling Mode | Normal sampling, peak detection, average |
