Brand: HAMMER
7-Meter Car Spray Booth
Model: SE-Z-8600
Country of Origin: China
The SE-Z-8600 car spray booth is the ideal choice for workshops and professionals seeking the highest levels of precision, quality, and safety during the painting process. It combines advanced engineering design with state-of-the-art ventilation and filtration systems to provide a completely clean working environment, ensuring that the vehicle exits the booth with top-quality paint finish while adhering to the strictest professional safety standards.
1. Dimensions & Panels
External Dimensions: 7000 × 5500 × 3400 mm (Length × Width × Height).
Internal Dimensions: 6900 × 3900 × 2650 mm, providing a comfortable workspace suitable for all car sizes.
Wall Panels: Made of 50 mm thick Rock Wool Board, flame-retardant to ensure excellent thermal insulation, high safety, and protection of internal equipment from external impacts.
2. Lighting System
Lighting Distribution: 8 precisely positioned lighting sets covering all corners of the booth.
Lamp Type: Each set includes 4 energy-saving LED lamps, providing bright and clear illumination for precise visibility of every detail during car painting, ensuring perfect and flawless finishing.
3. Technical Specifications & Control Systems
A. Makeup Air Unit
Equipped with 2 fans of 4 kW each, totaling 8 kW, ensuring a stable and strong airflow inside the booth.
This airflow helps remove dust and impurities from the car surface during painting, maintaining the paint quality.
B. Filtration System
Features a three-stage filtration system to ensure clean, impurity-free air:
Filter Bag: For primary filtration and removal of large particles.
Ceiling Filter: Purifies incoming air from above, protecting the paint.
Floor Filter: Made of fiberglass to capture excess paint overspray and prevent accumulation on the floor.
C. Control System
Fully integrated control panel for easy operation of all booth functions:
Power, lighting, and fan switches.
Temperature Setting Unit to accommodate different paint types.
Time Setting Unit to control the duration of drying and spraying processes.
Emergency Stop for quick response to any emergency, ensuring safety of personnel and equipment.
D. Optional Configuration
Booth capabilities can be enhanced according to workshop needs:
Activated Carbon Cabinet for additional air purification and odor removal.
Explosion-Proof Lighting and Electrical Panels to ensure maximum safety when handling flammable materials.
Smoke Concentration Alarms to monitor air quality in real-time.
| Name | - |
|---|---|
| Structure | Advanced steel frame for stability and durability |
| Control System | Integrated system for temperature, airflow, and lighting |
| Lighting | LED lighting for uniform illumination |
| Airflow | Stable airflow to remove dust and impurities |
| Filtration | Three-stage system: filter bag, ceiling filter, floor filter |
| Burners | Heating capacity: 200 kW with explosion prevention & rain cover |
| Dimensions | Overall size for vehicle accommodation |
| Compliance | Certifications for safety and quality |
| Standards | Compliant with international safety and quality standards |
| Customization | Optional configurations: activated carbon, explosion-proof panels, alarms |
| Control Panel | Full control panel with switches, emergency stop, temperature & time settings |
| FLOOR | Fiberglass floor for overspray collection |
| INTERNAL DIMENSIONS | 6900 × 3900 × 2650 mm |
| EXTERNAL DIMENSIONS | 7000 × 5500 × 3400 mm |
| MAIN DOOR | Full-size steel door with safety lock |
| SERVICE DOOR | Standard personnel access door |
| WALLS | 50 mm rock wool panels, flame-retardant |
| CEILING | Integrated ceiling structure with roof filter |
| TOP LIGHTING | LED ceiling lights, 8 sets × 4 lamps |
| SIDE LIGHTING | LED side lights |
| ROOF FILTER | High-efficiency ceiling filter |
| FLOOR FILTER | Fiberglass floor filter |
| CONTROL VIA PNEUMATIC GATE | Optional pneumatic control system |
| HEAT EXCHANGER | Integrated system for uniform temperature, 200 kW |
| EXHAUST UNIT | 1 turbine, 4 kW, total capacity 12,500 m³/h |
| CHIMNEY | Exhaust chimney for safe ventilation |
| POWER SUPPLY | 380V / 50Hz |
| FREQUENCY | 50 Hz |
| Insulation | Rock wool panels, 50 mm thick, flame-retardant |
| Exhaust Turbines (Suction) | 2 turbines, each 3 kW, total 6 kW, capacity 21,000 m³/h |
